歐美晶振
- 產品型號：1832430
- 晶振頻率：32.768KHz
- 晶振尺寸：7.0*1.5*1.4mm
- 產品應用： Geyer晶振,KX-327L音叉晶體,無源晶振,12.87132晶振,7015mm晶振,石英晶體諧振器,SMD晶振,四腳貼片晶振,頻率32.768KHz,負載7.0pF,頻率容差20ppm,工作溫度-20~70°C,高可靠性晶振,低老化晶振,耐環境特性晶振,時鐘鐘表晶振...
-
12.87132|32.768KHz|7.0pF|格耶SMD音叉晶體
12.87132|32.768KHz|7.0pF|格耶SMD音叉晶體,Geyer晶振,KX-327L音叉晶體,無源晶振,12.87132晶振,7015mm晶振,石英晶體諧振器,SMD晶振,四腳貼片晶振,頻率32.768KHz,負載7.0pF,頻率容差20ppm,工作溫度-20~70°C,高可靠性晶振,低老化晶振,耐環境特性晶振,時鐘鐘表晶振,兒童學習產品晶振,智能體溫計晶振,家用電器晶振.
12.87132|32.768KHz|7.0pF|格耶SMD音叉晶體規格表
| part no. | 12.87132 |
| model | KX-327L |
| frequency | 32.768 kHz |
| operating temperature | -20~+70℃ |
| frequency tolerance(df/F) at +25°C ±3°C | 土20ppm |
| temperature tolerance (parabolic coefficient) |
( -0.033 ±10 % ) × 10-6 / ℃2
|
| turnover temperature | +25°C±5℃ |
| storage temperature range | -55°C~+125℃ |
| load capacitance CL | 7.0 pF |
| shunt capacitance C0 typ. | 0.8 pF |
| series resistance R1 (ESR) max. | 65 KOhm |
| aging at +25°℃ (first year) max. | ±3 ppm |
| drive level | 1 μW max. |
| contents of reel | 3000 pcs. |
.jpg)
12.87132|32.768KHz|7.0pF|格耶SMD音叉晶體尺寸圖
