歐美晶振
- 產品型號：99562853
- 晶振頻率：9.81713MHz
- 晶振尺寸：3.2*2.5*0.9mm
- 產品應用： GEYER晶振,KX-7T進口貼片晶振,無源晶振,12.60195晶振,石英晶體諧振器,3225mm晶振,四腳貼片晶振,SMD晶振,頻率9.81713MHz,負載10pF,頻率容差30ppm,工作溫度-40~85°C,高穩定性晶振,高品質晶振,低老化晶振,無線通信晶振,...
-
12.60195|9.81713MHz|10pF|GEYER晶振
12.60195|9.81713MHz|10pF|GEYER晶振,GEYER晶振,KX-7T進口貼片晶振,無源晶振,12.60195晶振,石英晶體諧振器,3225mm晶振,四腳貼片晶振,SMD晶振,頻率9.81713MHz,負載10pF,頻率容差30ppm,工作溫度-40~85°C,高穩定性晶振,高品質晶振,低老化晶振,無線通信晶振,便攜式電子設備晶振,固態硬盤晶振,數字電視晶振.
12.60195|9.81713MHz|10pF|GEYER晶振規格表
| part no. | 12.60195 |
| model | KX-7T |
| frequency range | 9.817130 MHz |
|
mode |
fundamental |
| operating temperature | -40~+85℃ |
| frequency tolerance at +25°C | 土30 ppm |
| temperature tolerance |
土50 ppm
|
| storage temperature range | -55°C~+125℃ |
| load capacitance CL | 10 pF |
| shunt capacitance C0 typ. | 3.0 pF |
| series resistance R1 (ESR) max. | 60 Ohm |
| aging at +25°℃ (first year) max. | ±2 ppm |
| drive level | 200 μW max. |
| contents of reel | 1000 pcs. |
.jpg)
12.60195|9.81713MHz|10pF|GEYER晶振尺寸圖
.jpg)
